Your Suspension Vial Filling Line Provider
- Peristaltic-pump filling — gentle, no shearing, ideal for particle-laden suspensions
- 4-pump filling + robotic stopper placement, no-bottle-no-fill / no-bottle-no-stopper
- Glass or plastic vials, 100–500 ml, filling accuracy ±1%, GMP
AIPAK Engineering Suspension Vial Filling Line
AIPAK Engineering suspension vial filling line is purpose-built for suspensions — liquids that carry solid particles and tend to settle, cling and clog. It integrates a bottle feeder, a 4-pump filling & stoppering machine and a single-head servo capping machine into one line for glass or plastic vials from 100 ml to 500 ml.
The heart of the line is peristaltic-pump filling: the liquid touches only the tubing, never the pump body — so there is no shearing, no dead-corner build-up of particles, easy cleaning and no cross-contamination. This gentle handling is exactly what suspensions, emulsions and shear-sensitive biologics need. Filling is paired with robotic stopper placement (no-bottle-no-fill, no-bottle-no-stopper) and single-head three-knife servo capping. Product-contact parts are 316L; the line changes over quickly between container sizes.
AIPAK Engineering delivers the suspension line as one linked system — feeding, peristaltic-pump filling, robotic stoppering and servo capping — with a spare mold set, SAT/FAT, IQ/OQ/PQ/DQ, GMP documentation and one-year warranty.
Suspension Vial Filling & Stoppering Line
Suspension Vial Filling-Stoppering-Capping Line (RQJS-4, 100–500 ml)
The complete suspension line links a bottle feeder, a 4-pump peristaltic filling & stoppering machine and a single-head servo capping machine for glass or plastic vials at 35–50 bottles/min, 100–500 ml. Peristaltic pumps handle particle-laden suspensions gently (no shearing, easy CIP); robotic stopper placement gives no-bottle-no-fill / no-bottle-no-stopper protection; three-knife servo capping seals securely. Filling accuracy ±1%. Switching to 316L stainless-steel pumps raises output to 40–50 bottles/min.
4-head peristaltic-pump filling — gentle on suspensions, easy to clean
Robotic stoppering, no-bottle-no-fill / no-bottle-no-stopper
Glass or plastic vials 100–500 ml, ±1%, quick changeover
Suspension Vial Filling Line — Technical Specification
| Item | Specification |
| Line model | RQJS-4 |
| Vial material | Glass or plastic (by specification parts) |
| Vial size | 100–500 ml |
| Filling pumps | 4-head peristaltic (316L stainless-steel pump optional) |
| Filling accuracy | ±1% |
| Stoppering | Single-head robotic, no-bottle-no-stopper |
| Capping | Single-head, three-knife servo |
| Stable output | 35–40 bottles/min (peristaltic) / 40–50 bottles/min (316L pump) |
| Design capacity | 60 bottles/min |
| Speed control | Frequency variable |
| Product-contact material | 316L stainless steel |
| Control | Siemens HMI, Mitsubishi PLC, Schneider, Panasonic sensors |
| Compliance | GMP, IQ/OQ/PQ/DQ, SAT/FAT |
