AIPAK Engineering Inspection & Detection Equipment
AIPAK Engineering inspection and detection equipment covers the quality-control step after filling, stoppering and capping — visual (light) inspection, container leak detection, and bottle-surface cleaning. The range handles ampoules, vials, lyophilized vials and oral liquid bottles from 1 ml to 500 ml, in fully automatic and semi-automatic configurations.
Visual inspection machines use high-speed industrial cameras and image-analysis software to detect foreign particles, cracks, fill-level and closure defects; leak detection uses high-frequency high-voltage (HVLD) sensing to find micro-holes and sealing defects without contacting the product; and bottle outside cleaning & drying removes residues from the container surface before labeling. All machines are built to GMP, with data recording to GAMP and validation documentation.
AIPAK Engineering provides the full container quality-control set — visual inspection, leak detection and surface cleaning — as standalone machines or integrated in-line, all GMP-compliant with validation support.
Visual Inspection / Light Inspection
Automatic Visual Inspection Machine for Ampoules
AIPAK Engineering automatic visual inspection machine for ampoules (APKDJ-400/600/800) is a single-machine double-station system that detects foreign particles, cracks, coke head/carbonization and closure defects in filled containers. Using infrared light and high-speed industrial cameras with image-analysis software, it inspects ampoules, vials and oral liquid bottles from 1–500 ml, automatically separating qualified and defective products.
Up to 800 bottles/min, single-machine double-station
Detects particles, glass chips, fibers, cracks & coke head
DD-motor direct drive, GAMP data recording
Automatic Visual Inspection Machine for Oral Liquid Bottles
AIPAK Engineering automatic visual inspection machine for oral liquid bottles uses high-speed cameras and automatic image tracking to check each bottle for foreign particles, fill level, closure and appearance defects. Qualified and defective bottles are automatically separated into their own channels, giving reliable in-line quality control for oral liquid production.
Camera inspection: foreign particles + fill level
High-speed image tracking with automatic reject
GMP-compliant, GAMP data recording
Automatic Visual Inspection Machine for Lyophilized Vials
AIPAK Engineering automatic visual inspection machine for lyophilized (freeze-dried) vials inspects cake appearance, foreign particles, closure and container defects. Purpose-configured for freeze-dried products, it uses high-speed camera detection with automatic rejection for reliable in-line inspection of lyophilized vial production.
Inspects cake appearance + foreign particles
Purpose-built for freeze-dried vials
Automatic reject, GMP-compliant
APKDJ-500 Semi-Automatic Light Inspection Machine
AIPAK Engineering APKDJ-500 semi-automatic light inspection machine is an operator-assisted station for visual inspection of ampoules, vials and oral liquid bottles under a standardized light source. It suits medium-batch production and flexible inspection needs where manual judgment is preferred, with a compact footprint and easy operation.
Operator-assisted inspection under standardized light
For ampoules, vials & oral liquid bottles
Compact, flexible, easy to operate
APKDJ-150 Series Semi-Automatic Light Inspection Machine
AIPAK Engineering APKDJ-150 series semi-automatic light inspection machine provides operator-assisted visual inspection for small-to-medium batch production. Available as a series for different throughput needs, it inspects ampoules, vials and oral liquid bottles under a standardized light source — a cost-effective, flexible inspection solution.
Semi-automatic, small-to-medium batch
Series configuration for different throughputs
Cost-effective, flexible inspection
Leak Detection
Ampoule/Vial Leak Detection Machine (HVLD)
AIPAK Engineering ampoule/vial leak detection machine (AJL300) uses high-frequency high-voltage (HVLD) sensing to detect micro-holes, cracks and sealing defects on the body, bottom and neck of filled containers. Non-destructive and non-contact — the electrodes never touch the product — it inspects 1–20 ml ampoules, vials and oral liquid bottles at 300–400 bottles/min, with a defect-reject system.
HVLD detection, 10–35 kV, non-destructive
300–400 bottles/min, 1–20 ml containers
Electrodes never contact product — no contamination
Bottle Surface Cleaning
Automatic Bottle Outside Cleaning and Drying Machine
AIPAK Engineering automatic bottle outside cleaning and drying machine (APKWX-300 to 600) removes drug residue from the outer surface of filled containers after capping, ensuring firm label adhesion and clean handling downstream. It uses rough + fine washing (with water recycling) and room-temperature air drying — no heating — for ampoules, vials and oral liquid bottles from 1–250 ml, up to 1,000 bottles/min.
Up to 1,000 bottles/min (10 ml basis), 1–250 ml
Room-temperature air drying, no heating
Rough + fine wash with water recycling
Inspection & Detection Equipment — Specification
| Machine | Model | Speed | Range | Method |
| Ampoule Visual Inspection | APKDJ-400/600/800 | 400–800 bpm | 1–500 ml | Camera + infrared |
| Leak Detection | AJL300 | 300–400 bpm | 1–20 ml | HVLD 10–35 kV |
| Bottle Outside Cleaning | APKWX-300~600 | 300–600 bpm (up to 1000) | 1–250 ml | Water wash + air dry |
| Oral Liquid Visual Inspection | — | — | — | Camera |
| Lyophilized Vial Inspection | — | — | — | Camera |
| APKDJ-500 Semi-Auto | APKDJ-500 | — | — | Light inspection |
| APKDJ-150 Semi-Auto | APKDJ-150 | — | — | Light inspection |
